Thermic Fluid Hot Oil Pump

Operating range

Capacity-Q- : Up to 300 M3/hr

Head : Up to 150 mlc

Pump Size – DN : 25 mm To 300 mm

Temperature : Up to + 350.C

Speed – N - : 1450/2900 RPM at 50 Hz & 3500 RPM at 60 Hz

Application

• Thermal Oil Circulation, Oil Refinery, Thermal Boiler.

• Edible Oil Circulation, Hot Water Circulation,

• Petro Chemical Industries, Boiler Industries, Textile industries

• Salt Industries , Solvent Industries

• Palm oil mills and Refineries, Food industries.

Sectional Drawing

1 Clearance Gap 2 Discharge Nozzle

3 Casing Cover 4 Shaft

5 Bearing Bracket 6 Suction Nozzle

7 Impeller 8 Plain Bearing

9 Shaft Seal 10 Motor End, Rolling Element Bearing

Materials

• Graded Cast Iron • Carbon Steel(WCB)

• Alloy Steel • CF8(SS 304)

• CF8M(SS 316) • CF3M(SS 316 L)

Features

• Easy Maintenance through the Back pull out Principle.

• Mechanical Seal Fitted.

• High Temp. Heat Transfer Fluid Transfer without Cooling.

• High efficiency hydraulic design

• Heavy duty shaft, and bearings

• Low NPSH

• Noise and maintenance free

• Steady head & capacity

• Several flange drilling options according to valid standards.

• Suitable with V-belt drive or direct coupled with a motor.
